Gate Valves

Gate Valves Manufacturer and Supplier in India

Gate valves are primarily designed to start or stop flow, and when a straight-line flow of fluid and minimum flow restriction are needed. In service, these valves generally are either fully open or fully closed.

The disk of a Gate valve is completely removed when the valve is fully open; the disk is fully drawn up into the valve Bonnet. This leaves an opening for flow through the valve at the same inside diameter as the pipe system in which the valve is installed. A Gate valve can be used for a wide range of liquids and provides a tight seal when closed.

Gate Valve Detailed Description

Size Range	1/4" to 40"
Design Standard	DIN, ASME, API, JIS, VG.
Pressure Class	- 150 to 4500 as per ASME. - PN 6 to 420 as per DIN.
Material of Construction	Cast Steel, Forged Steel, Cast Iron Nickel Aluminium Bronze, AB2, Brass, Bronze, Gunmetal.
End Connections	Flanged, Butt welded, Threaded, Socket Welded.
Mode of Operating	Hand wheel, Electrical Actuated, Pneumatic Actuated, Hydraulic Actuated.
